Best 7KC3DDS3 Storeroom Lever Lock
Grade 2 commercial-medium duty storeroom lever lock.
The Best Access Systems 7KC3D Storeroom function medium/commercial duty lever lockset. Storeroom function, Outside lever is always locks. Outside lever cannot be unlocked. Latch is operated by turning key in in (outside) lever or by rotating inside lever. Inside lever can never be locked. Inside lever is always unlocked and free for immediate exit. For buildings with medium traffic flow.
Click here for Best Access Systems 7KC3 catalog.
Click here for installation instructions
Details and product specs of the Best 7KC3DDS3 Storeroom Lever Lock
|Series & Type:||7KC3 / Grade 2 commercial cylindrical lever lock|
|Function:||D - Storeroom Function: Outside lever is always locks. Outside lever cannot be unlocked. Latch is operated by turning key in in (outside) lever or by rotating inside lever. Inside lever can never be locked. Inside lever is always unlocked and free for immediate exit.|
Conventional Cylinder (keyed); or
SFIC housing only (permanent core by others). SFIC access all Best
|Keying:||Keyed Random (different) or Keyed-Alike - on conventional cylinder only; SFIC is supplied less core (permanent core by others).|
|Rose Type:||D-Style - 3 1/2"|
|Door Thickness:||1 3/8" - 2 3/4"|
613-Oil Rubbed Bronze;
16-Curved, no return.
|UL Listed:||UL Listed for 3-hour A label single swinging doors (4' x 8' ) fire doors.|
|ANSI:||A156.3, Grade 2|
|Through-Bolt:||Yes - Through-bolt mounting studs increase torque resistance.|
|Latch:||1/2” throw deadlocking latch, front: 2 1/4” x 1 1/8”.|
|Strike Plate:||S3 ANSI strike -4 7/8” x 1 1/4” with curved lip in box. (ANSI A115.2 for 1 3/4” doors).|
|Mfg Model #||7KC3__DDS3|
|MDI Model #:||7KC3-D|
