HM Glazing Bead Stop Molding 5/8-inch x 5/8-inch with Tek Screws

Item #:
P-HMGBS
Retail Price:
$24.00
MDI Price:
$15.00 you save: $9.00 (38%)
Availability:
Usually ships in 2-3 business days
Length:
Please select a Length...
Quantity:
  • Description

Hollow Metal Glazing Bead Stops w/ Tek Screws
Supplied with Tek Screws

Removable U-shaped channel secures glass (or panel) to the light opening in doors and frames.  Typically used on HM steel doors and frames.

- A40 galv. steel. (superior to CRS).
- Stop size: 5/8" x 5/8"
- Stop gauge: 18 gauge
- Punched & dimpled (counter-sunk) for screws.
- Pre-drilled counter-sunk screw preps are at 12" CTC (Center-To-Center).
- Installation Tek (self-drilling) screws are included.
- Can be field-cut to any size required.
- Lengths Available: 3', 4', 5', 6', 7'.  *

* Up to 10'-0" lengths are available but will have to be quoted due to oversized shipping charges.  Please contact our office for a special order price quote.
